Tuam Tshoj Machinery International Trading Co., Ltd. yog ib tug ua manufacturers thiab lwm tus neeg ntawm 600kg hydrostatic loader|jh7706 ua. Nrog kev paub ntau ntxiv, peb zoo siab tos txais koj los yuav pheej yig 600kg hydrostatic loader|jh7706 ua nyob rau hauv Suav teb nov los ntawm peb lub hoobkas. Rau nqe kev sab laj, tiv tauj peb.
Qhov zoo ntawmHydrostatic Log Loader
Transmission System:
Ua haujlwm hloov pauv hloov piston twj tso kua mis + hydraulic lub cev muaj zog (kaw-loop), uas muaj cov kab ke sib kis tau zoo.
Tswj ceev:
Steplessly adjustable ceev nrog smooth hloov.
Kev ua haujlwm zoo:
Cov lus teb ceev ceev thiab kev tswj xyuas meej.
Roj Efficiency:
High efficiency, txuag 10-20% ntawm roj.
Kev Ua Haujlwm Zoo:
Kev ua haujlwm du heev.
Tsim nyog Scenario:
Haum rau nruab nrab - cov loaders loj hauv cov xwm txheej uas yuav tsum tau ua haujlwm rau pem hauv ntej / thim rov qab.
Main specification
|
Yam khoom / Model |
7706 |
7708 |
|
Zuag qhia tag nrho Length (A): mm |
4295 |
4235 |
|
Wheelbase (B): mm |
1400 |
1560 |
|
Av Clearance (C): mm |
270 |
400 |
|
Kev khawb qhov tob (D): mm |
155 |
|
|
Tag nrho lub log dav (E): mm |
1146 |
1310 |
|
Lub log Center nrug (F): mm |
865 |
930 |
|
Max Boom Lifting Qhov siab (G): mm |
2785 |
2958 |
|
Tshaj tawm qhov nrug (H): mm |
757 |
605 |
|
Zuag qhia tag nrho qhov siab (Min Transport Height, I): mm |
2203 |
2470 |
|
Thawv Rollback Angle (J) |
55 |
55 |
|
Lub kaum ntse ntse (K) |
35 |
35 |
|
Zuag qhia tag nrho ntev (tsis muaj thoob, L) |
3535 |
3475 |
|
Zuag qhia tag nrho Length (Nrog thoob, M) |
4445 |
4385 |
|
Dumping Qhov siab (N): mm |
1982 |
2155 |
|
Loading Qhov siab (O): mm |
2478 |
2650 |
|
Cav |
Kubota D1105 |
Kubota D1105 |
|
Luj: T |
2 |
2.3 |
|
Hloov Radius: mm |
Mini 1641, Max 3438 |
Mini 1749, Max 3344 |
|
Steering Angle |
35 |
35 |
|
Lub log dav: mm |
260 |
380 |
|
Tyre Model |
26*12.00-12 |
31-15.5-15-3 |
|
Lub taub ntim: m³ |
0.25 |
0.25 |
|
Roj Tank Peev Xwm: L |
30 |
30 |
|
Ua haujlwm siab: Mpa |
16 |
16 |
|
Kev ceev ceev: KM/h |
14 |
14 |
|
Max Lifting Sijhawm: s |
5 |
5 |
|
Up/down Swing Angle (Sab Ib Sab): degree |
6 degree |
6 degree |
|
Lifting Nyhav: KG |
600 |
800 |
|
Max Steering Angle Lifting Nyhav: KG |
400 |
530 |
|
Yam tsawg kawg nkaus hauv av Clearance: mm |
170 |
245 |
